And I enter Password1 in the Password field And I click the Log In button
In the initial version of the test steps that I wrote, I made steps like this reusable by allowing the test creator to enter custom data in reusable steps:
And I enter "Password1" in the "Password" field And I click the "Log In" button
Where the text in parentheses is a variable, allowing the same step to be used for any similar field:
And I enter "johndoe" in the "Username" field And I enter "Password1" in the "Password" field
<label for="username">Username</label> <input type="text" name="username>
Another example step:
And I click the "Submit" button
which corresponds to this DOM element:
<input type="submit" value="Submit">
For our applications that are actively under development, we discussed the need for consistent UI conventions with our developers and they agreed to abide by a set of UI design patterns. Since the agreed upon patterns represented best practices in HTML UI development in addition to making automation easier, our developers were agreeable. Afterwards, if we started to automate a new UI screen and discovered that it did not conform to the agreed-upon patterns, we filed a design-for-testability bug and the UI would be changed.
In the next phase of our automation project, we began to to automate some of our legacy applications, and we quickly discovered that the developers had not been nearly as consistent with the UI designs of these applications: the assumptions behind our existing cucumber steps did not always hold true. Since these applications will eventually be phased out, the company is carefully limiting the amount of development work that is put into them. Therefore, we could not request that the UIs be changed to enable them to conform to the design patterns we had agreed upon for our new UIs.
To accommodate automation of these applications, we had to deviate from the cucumber principle that the test writer doesn’t need to know any more about the UI than what they can see. We developed some steps for other common UI patterns, and our automated test developers had to look at the DOM of the elements they needed to interact with in order to decide which step to use, such as:
And I enter "johndoe" in the input text field with name "username"
which corresponds to the input text field:
<input type="text" name="username">
And I click the button that contains the text "Submit"
which corresponds to:
(In that step, the ‘contains’ is the part that requires the user to understand the DOM and which differentiates this step from other steps related to buttons).
To my pleasant surprise, even our manual testers who didn’t really have any significant experience with HTML or the DOM learned these UI patterns quickly and adapted to them.
For the most part, we discovered that the UIs of our legacy applications, while not as conducive to the spirit of cucumber, still used only a fairly small set of UI conventions. We coded some more reusable steps for those other conventions and covered probably 90% of the cases that we encountered.
Eventually, I had to add some steps for the more obtuse UI design cases, such as:
And I enter "johndoe" in the "input" field with attribute "custom_attribute_name" with value "x_username"
I’m the first to admit that that is an ugly, ugly step, but steps like this allow us to automate the other 10% of UI designs that lie outside the conventions outlined above, and we’ve only had to use these types of steps a few times.
It did not take us long to create a library of steps that accommodate all of our standard UI interactions. I don’t think I’ve added a general-purpose UI interaction step in a couple of months, which is awesome.
For the next phase in the evolution of our automation framework, I’m thinking of using the XPATH ‘or’ attribute to collapse multiple steps back into one, but that may end up being more confusing to our test writers, especially if I can collapse some similar steps but not all of the same type. We’ll see.
